DNV 2.7.1 cargo carrying units, CCUs and containers
Rental and sales of many types in Trinidad and Tobago
New DNV offshore containers and CCU's built & tested according to DNV 2.7.1 EN 12079 standards.
Hire and Sale from depots on Trindad.
Now also available in Guyana, Surinam and Granada
DNV offshore containers for hire and sale from depots in TT:
To meet demands from the Trinidad offshore oil and gas industries we supply our range of 5ft. to 20ft. DNV 2.7.1 standard and special containers and ccus for hire and sale.
Brochure
TITAN offshore 2017
5' - CCU Mini container
| |
Length mm |
Width mm |
Height mm |
| External |
1,690 |
1.960 |
2.770 |
| Internal |
1.480 |
1.740 |
2.410 |
| Tare weight |
1700 kgs |
|
|
| Cargo |
4000 kgs |
|
|
| Maximum |
5700 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
- Built and certified DNV 2.7-1 EN 12079-1
6' CCU - standard container
| |
Length mm |
Width mm |
Height mm |
| External |
1,830 |
1,830 |
2,438 |
| Internal |
1,668 |
1,738 |
2,169 |
| Tare weight |
1500 kgs |
|
|
| Cargo |
2500 kgs |
|
|
| Maximum |
4000 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
8' CCU - standard container
| |
Length mm |
Width mm |
Height mm |
| External |
2,438 |
1,968 |
2,591 |
| Internal |
2,276 |
1,876 |
2,322 |
| Tare weight |
1560 kgs |
|
|
| Cargo |
2440 kgs |
|
|
| Maximum |
4000 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - standard container
| |
Length mm |
Width mm |
Height mm |
| External |
2,991 |
2,438 |
2,591 |
| Internal |
2,829 |
2346 |
2,381 |
| Tare weight |
1960 kgs |
|
|
| Cargo |
9540 kgs |
|
|
| Maximum |
11500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - hard top open top - lift off roof
| |
Length mm |
Width mm |
Height mm |
| External |
2,991 |
2,438 |
2,591 |
| Internal |
2,829 |
2,346 |
2,251 |
| Tare weight |
2600 kgs |
|
|
| Cargo |
10400 kgs |
|
|
| Maximum |
13000 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - open top with tarpaulin
| |
Length mm |
Width mm |
Height mm |
| External |
2,991 |
2,438 |
2,591 |
| Internal |
2,833 |
2,344 |
2,250 |
| Tare weight |
2200 kgs |
|
|
| Cargo |
7800 kgs |
|
|
| Maximum |
10000 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - ½ height open top with tarpaulin or bin container
| |
Length mm |
Width mm |
Height mm |
| External |
2,991 |
2,438 |
1,280 |
| Internal |
2,833 |
2,344 |
.940 |
| Tare weight |
1700 kgs |
|
|
| Cargo |
8460 kgs |
|
|
| Maximum |
10160 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Suitable for use with or without tarpaulins
- End doors
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - ½ height basket/bin
| |
Length mm |
Width mm |
Height mm |
| External |
2-991 |
2,438 |
1.280 |
| Internal |
2.760 |
2.250 |
0.990 |
| Tare weight |
1700 kgs |
|
|
| Cargo |
10000 kgs |
|
|
| Maximum |
11.700 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
- Built and certified DNV 2.7-1 EN 12079-1
10' CCU - refrigerated container
| |
Length mm |
Width mm |
Height mm |
| External |
2,991 |
2,438 |
2,591 |
| Internal |
2,381 |
2,284 |
2,261 |
| Tare weight |
2980 kgs |
|
|
| Cargo |
7820 kgs |
|
|
| Maximum |
10800
kgs
|
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- -40c to + 30c thermostat controlled
- Modern power efficient marine refrigeration
- Hygienic stainless steel interior with aluminium T section floors
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - standard container
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,591 |
| Internal |
5,896 |
2,346 |
2,352 |
| Tare weight |
2970 kgs |
|
|
| Cargo |
13530 kgs |
|
|
| Maximum |
16500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - standard container with doors in both ends
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,591 |
| Internal |
5,844 |
2,346 |
2,352 |
| Tare weight |
3600 kgs |
|
|
| Cargo |
12900 kgs |
|
|
| Maximum |
16500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - standard container high cube
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,896 |
| Internal |
5,896 |
2,346 |
2,686 |
| Tare weight |
3290 kgs |
|
|
| Cargo |
13200 kgs |
|
|
| Maximum |
16500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - hard top open top - lift off roof
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,591 |
| Internal |
5,896 |
2,346 |
2,251 |
| Tare weight |
4180 kgs |
|
|
| Cargo |
12320 kgs |
|
|
| Maximum |
16500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - Open top with tarpaulin
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,591 |
| Internal |
5,896 |
2,240 |
2,360 |
| Tare weight |
3700 kgs |
|
|
| Cargo |
12000 kgs |
|
|
| Maximum |
15700 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - ½ height open top with tarpaulin or bin container
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
1,280 |
| Internal |
5,896 |
2.346 |
.940 |
| Tare weight |
2490 kgs |
|
|
| Cargo |
14010 kgs |
|
|
| Maximum |
16500 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- Suitable for use with or without tarpaulins
- End doors
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - ½ height basket/bin
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
1,280 |
| Internal |
5,860 |
2.150 |
0,.900 |
| Tare weight |
2900 kgs |
|
|
| Cargo |
13100 kgs |
|
|
| Maximum |
16000 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
- Side doors
- Built and certified DNV 2.7-1 EN 12079-1
20' CCU - refrigerated container
| |
Length mm |
Width mm |
Height mm |
| External |
6,058 |
2,438 |
2,591 |
| Internal |
5,448 |
2,284 |
2,261 |
| Tare weight |
4380 kgs |
|
|
| Cargo |
9820 kgs |
|
|
| Maximum |
14200 kgs |
|
|
| Dimensions are indicative and may vary according to series and specifications |
Picture gallery
- Higher level door handles for easier site operations on many units.
- -40c to + 30c thermostat controlled
- Modern power efficient marine refrigeration
- Hygienic stainless steel interior with aluminium T section floors
- Built and certified DNV 2.7-1 EN 12079-1
- We hold local depot stocks as well as factory stocks of
most types.
- Other types and sizes can be built for sale or hire with
approx 10-14 weeks lead time.
- We already offer special models CCU's like 20' with
container doors in both ends and CCU's with various heights
up to 9'6" high
- DNV office and workshop models are also available.
- We have an approved design for complient
DNV accomodation units.
- We can also supply ATEX compliant refrigerated and
accomodation containers
We are always looking to expand the product range and no quantity is too small. Competitive terms - spot, short or long term rentals.
